Oxygen Cylinders

Name: Oxygen Cylinders
Brand: MY SHOP
SKU: Oxygen Cylinders
Availability: InStock
Rating: 5 (1 reviews)

No.Oxygen Cylinders

Oxygen Cylinders ₂

Core Parameters

Design Pressure: 15MPa/20MPa, Working Pressure: 13.5MPa/15MPa
Material: 37Mn/34CrMo4 Alloy Steel, Inner surface degreasing treatment (to prevent oil explosion)
Applicable Scenarios: Medical First Aid, Industrial Cutting, Welding, Metallurgy

Oxygen Cylinders

Oxygen Cylinders ₂ Core Parameters Design Pressure: 15MPa/20MPa, Working Pressure: 13.5MPa/15MPa Material: 37Mn/34CrMo4 Alloy Steel, Inner surface degreasing treatment (to prevent oil explosion) Applicable Scenarios: Medical First Aid, Industrial Cutting, Welding, Metallurgy

Get The Latest Quote

Description

Oxygen Cylinders

I. General Basic Parameters

Parameter Category	Core Indicators	Remarks
Volume Range	1L/2L/4L/8L/10L/20L/40L/50L	Small volume for portability; large volume for industrial bulk use
Design Pressure	15MPa/20MPa/25MPa	Customized according to medium characteristics
Working Pressure	13.5MPa/15MPa/20MPa	Complies with standards such as ISO 9809, DOT-3AA, TPED
Material	37Mn/34CrMo4 alloy steel seamless; carbon steel/composite material foracetylene	High strength, fatigue resistance, passing water pressure/rupture test
Cylinder Valve	CGA/DIN/JIS standard interface	Adapts to filling equipment in different regions
Implementation Standards	ISO 9809-1/-2, DOT-3AA, TPED, GB 5099	Covers certifications of global mainstream markets
Safety Accessories	Cylinder valve with overcurrent protection/fusible plug, shockproof rubber ring, cylinder cap	Complies with dangerous goods transportation safety regulations

II. Core Parameters by Medium and Global Selling Points

Oxygen Cylinders ₂

Core Parameters

Design Pressure: 15MPa/20MPa, Working Pressure: 13.5MPa/15MPa
Material: 37Mn/34CrMo4 Alloy Steel, Inner surface degreasing treatment (to prevent oil explosion)
Applicable Scenarios: Medical First Aid, Industrial Cutting, Welding, Metallurgy

Global Selling Points

Europe: Medical-grade certification (EN ISO 13485), suitable for hospital/first aid scenarios; TPED certification supports cross-border transportation.
America: DOT certification, medical models comply with FDA standards; industrial models adapted to metallurgy/welding; portable models (1-10L) for outdoor first aid.
Southeast Asia: Dual medical/industrial models, humid-heat resistant design, suitable for medical first aid/aquaculture oxygenation, high cost-effectiveness.
Middle East: High-temperature resistant design, suitable for oilfield exploitation/medical first aid; large-volume models for industrial use.
Africa: Medical models adapted to primary medical care; industrial models for infrastructure welding, supporting local after-sales service.
